The FusionServer 2288H V6 is a 2U 2-socket rack server with flexible configurations, designed for cloud computing, virtualization, database, and big data workloads. It can be configured with 2-socket Intel® Xeon® Scalable processors, 32 DDR4 RAM slots, and 14 PCIe expansion slots, supporting massive local storage resources.
| Server Model | FusionServer 2288H V6 |
| Form Factor | 2U rack server |
| Processors | One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), TDP up to 270 W |
| Local Storage | Supports 8-31 x 2.5-inch SAS/SATA/SSD; 12-20 x 3.5-inch SAS/SATA; 4/8/16/24 NVMe SSDs; Dual M.2 SSDs |
| RAID Support | RAID 0, 1, 10, 1E, 5, 50, 6, or 60; optional supercapacitor for cache data power failure protection |
| Network | OCP 3.0 NICs via FlexIO card slots; Hot swappable function supported |
| PCIe Expansion | Up to 14 PCIe 4.0 slots (including dedicated RAID and OCP 3.0 slots) |
| Chip Set | Intel C621A |
| Management | iBMC chip (Redfish, SNMP, IPMI 2.0, HTML5/VNC KVM); Optional FusionDirector software |
| Operating Systems | Windows Server, SUSE Linux, VMware ESXi, Red Hat Enterprise Linux, CentOS, Ubuntu, Debian, etc. |
| Power Supply | Platinum/Titanium PSUs: 900W, 1200W, 1500W, 2000W, 3000W options; 1+1 redundancy |
| Dimensions | 86.1 mm x 447 mm x 790 mm |
As a leading integrated IT solutions provider, we combine cutting-edge manufacturing, dedicated R&D facilities, and a robust global distribution network. With 15 years of expertise in designing and maintaining mission-critical IT environments, we provide computing servers, network storage, and enterprise-grade accessories.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
