FusionServer 2288H V6 2U Rack Server
The FusionServer 2288H V6 is a versatile 2U 2-socket rack server designed with flexible configurations to meet the demands of cloud computing, virtualization, database management, and big data workloads. Powered by 2-socket Intel® Xeon® Scalable processors, it supports up to 32 DDR4 RAM modules and 14 PCIe expansion slots, offering expansive local storage resources.
Equipped with patented technologies like DEMT (Dynamic Energy Management Technology), intelligent power management, and FDM (Fault Diagnosis & Management), it ensures high efficiency and reliability while reducing operational costs and maximizing ROI.
| Server Model | FusionServer 2288H V6 |
| Form Factor | 2U rack server |
| Processors | One or two 3rd Gen Intel® Xeon® Scalable Ice Lake processors (8300/6300/5300/4300 series), TDP up to 270 W |
| Local Storage | Supports hot swappable drives: • 8-31 x 2.5-inch SAS/SATA/SSD • 12-20 x 3.5-inch SAS/SATA • 4/8/16/24 NVMe SSDs • Dual M.2 SSDs |
| RAID Support | RAID 0, 1, 10, 1E, 5, 50, 6, 60; Optional supercapacitor for cache protection; Remote web-based configuration. |
| Network | OCP 3.0 NICs supported via two FlexIO card slots; Multiple network expansion types available. |
| PCIe Expansion | Maximum of 14 PCIe 4.0 slots (including dedicated RAID and OCP 3.0 slots). |
| Chipset | Intel C621A |
| Management | iBMC chip with dedicated GE port; Supports Redfish, SNMP, IPMI 2.0; Optional FusionDirector software for full lifecycle management. |
| Operating Systems | Windows Server, SUSE Linux, VMware ESXi, Red Hat, CentOS, Oracle, Ubuntu, Debian, etc. |
| Security | TPM 2.0, Power-on password, Admin password, Secure boot, Chassis cover opening detection. |
| Dimensions | 86.1 mm x 447 mm x 790 mm (3.39 in. x 17.60 in. x 31.10 in.) |
| Power Supply | 1+1 Redundant hot-swappable PSUs (Options: 900W, 1200W, 1500W, 2000W, 3000W; AC/HVDC/DC). |
